Abracon Corporation ASDMPC-14.7456MHZ-LR-T3
- Mfg. Part Number
- ASDMPC-14.7456MHZ-LR-T3
- Manufacturer
- Abracon Corporation
- Product Category
- Oscillators
- Brief Description
- OSC MEMS 14.7456MHZ CMOS SMD
- Datasheet Download
- ASDMPC-14.7456MHZ-LR-T3.pdf
Availability of ASDMPC-14.7456MHZ-LR-T3
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.82600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ASDMPC-14.7456MHZ-LR-T3, we specialize in Abracon Corporation all series electronic components. ASDMPC-14.7456MHZ-LR-T3 can be shipped within 24 hours after order. If you have any demands for ASDMPC-14.7456MHZ-LR-T3, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ASDMPC-14.7456MHZ-LR-T3 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ASDMPC-14.7456MHZ-LR-T3
| Internal Part Number | EIS-ASDMPC-14.7456MHZ-LR-T3 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS2/REACH Compliance | |
| 3D Model | ASDMP.pdfASDMP.stp | |
| Standard Package | 3,000 | |
| Category | Crystals and Oscillators | |
| Family | Oscillators | |
| Series | Pure Silicon™ ASDMP | |
| Packaging | Tape & Reel (TR) | |
| Type | MEMS (Silicon) | |
| Frequency | 14.7456MHz | |
| Function | Tri-State (Output Enable) | |
| Output | CMOS | |
| Voltage - Supply | 2.25 V ~ 3.6 V | |
| Frequency Stability | ±25ppm | |
| Operating Temperature | -40°C ~ 85°C | |
| Current - Supply (Max) | 35mA | |
| Ratings | - | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.098" L x 0.079" W (2.50mm x 2.00mm) | |
| Height | 0.033" (0.85mm) | |
| Package / Case | 6-SMD, No Lead (DFN, LCC) | |
| Current - Supply (Disable) (Max) | 95µA | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ASDMPC-14.7456MHZ-LR-T3 | |
| Related Links | ASDMPC-14.7, ASDMPC-14.7456MHZ-LR-T3 Datasheet, Abracon Corporation Distributor | |
