Atmel ATF1504AS-7AC100
- Mfg. Part Number
- ATF1504AS-7AC100
- Manufacturer
- Atmel
- Product Category
- Embedded - CPLDs (Complex Programmable Logic Devices)
- Brief Description
- IC CPLD 64MC 7.5NS 100TQFP
- Datasheet Download
- ATF1504AS-7AC100.pdf
Availability of ATF1504AS-7AC100
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ATF1504AS-7AC100, we specialize in Atmel all series electronic components. ATF1504AS-7AC100 can be shipped within 24 hours after order. If you have any demands for ATF1504AS-7AC100, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ATF1504AS-7AC100 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ATF1504AS-7AC100
| Internal Part Number | EIS-ATF1504AS-7AC100 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 90 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - CPLDs (Complex Programmable Logic Devices) | |
| Series | ATF15xx | |
| Packaging | Tray | |
| Programmable Type | In System Programmable (min 10K program/erase cycles) | |
| Delay Time tpd(1) Max | 7.5ns | |
| Voltage Supply - Internal | 4.75 V ~ 5.25 V | |
| Number of Logic Elements/Blocks | - | |
| Number of Macrocells | 64 | |
| Number of Gates | - | |
| Number of I/O | 64 | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 100-TQFP | |
| Supplier Device Package | 100-TQFP (14x14) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ATF1504AS-7AC100 | |
| Related Links | ATF1504A, ATF1504AS-7AC100 Datasheet, Atmel Distributor | |
ATF1504AS-7AC100 Details Description
