Advanced Thermal Solutions Inc. ATS-03C-129-C3-R0

ATS-03C-129-C3-R0 picture photo
Mfg. Part Number
ATS-03C-129-C3-R0
Manufacturer
Product Category
Thermal - Heat Sinks
Brief Description
HEATSINK 60X60X10MM XCUT T412
Datasheet Download
ATS-03C-129-C3-R0.pdf
Availability of ATS-03C-129-C3-R0

Available Quantity

5020 Pieces

Can ship today

Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks

Marketing Price
$ 8.61000
Our Price
Quote by Email

QUANTITY



EIS Components is the stocking Distributor of ATS-03C-129-C3-R0, we specialize in Advanced Thermal Solutions Inc. all series electronic components. ATS-03C-129-C3-R0 can be shipped within 24 hours after order. If you have any demands for ATS-03C-129-C3-R0, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
ATS-03C-129-C3-R0 Order Process
Add Parts to RFQ form
Submit RFQ
We reply within 24 hours
You confirm order
Payment
Ship out your order
Specifications of ATS-03C-129-C3-R0
Internal Part NumberEIS-ATS-03C-129-C3-R0
Lead Free Status / RoHS StatusLead free / RoHS Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
Production Status (Lifecycle)In Production
ConditionNew & Unused, Original Sealed
Video FileHow to Install Push Pin Heat Sinks
Design ResourcespushPIN™ Selector Tool
Featured ProductATS - pushPIN™ Heat-sinks
Standard Package1
Category Fans, Thermal Management
FamilyThermal - Heat Sinks
SeriespushPIN™
TypeTop Mount
Package CooledAssorted (BGA, LGA, CPU, ASIC...)
Attachment MethodPush Pin
ShapeSquare, Fins
Length2.362" (60.00mm)
Width2.362" (60.00mm)
Diameter-
Height Off Base (Height of Fin)0.394" (10.00mm)
Power Dissipation @ Temperature Rise-
Thermal Resistance @ Forced Air Flow8.71°C/W @ 100 LFM
Thermal Resistance @ Natural-
MaterialAluminum
Material FinishBlue Anodized
Weight0.001 KG
ApplicationEmail for details
Alternative Part (Replacement)ATS-03C-129-C3-R0
Related LinksATS-03C-, ATS-03C-129-C3-R0 Datasheet, Advanced Thermal Solutions Inc. Distributor
ATS-03C-129-C3-R0 Details Description
