International Rectifier (Infineon Technologies Americas Corp.) AUIPS1021S
- Mfg. Part Number
- AUIPS1021S
- Manufacturer
- International Rectifier (Infineon Technologies Americas Corp.)
- Product Category
- PMIC - Power Distribution Switches, Load Drivers
- Brief Description
- IC SW IPS 1CH LOW SIDE D2PAK
- Datasheet Download
- AUIPS1021S.pdf
Availability of AUIPS1021S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AUIPS1021S, we specialize in International Rectifier (Infineon Technologies Americas Corp.) all series electronic components. AUIPS1021S can be shipped within 24 hours after order. If you have any demands for AUIPS1021S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AUIPS1021S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AUIPS1021S
| Internal Part Number | EIS-AUIPS1021S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | High Voltage Integrated Circuits (HVIC Gate Drivers) | |
| PCN Obsolescence/ EOL | Multiple Devices 27/Aug/2015 | |
| PCN Assembly/Origin | Qualification PCube IPS Technology 23/Jun/2014 | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Series | Automotive, AEC-Q100 | |
| Packaging | Tube | |
| Switch Type | General Purpose | |
| Number of Outputs | 1 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | Low Side | |
| Output Type | N-Channel | |
| Interface | On/Off | |
| Voltage - Load | 36V (Max) | |
| Voltage - Supply (Vcc/Vdd) | Not Required | |
| Current - Output (Max) | 4.8A | |
| Rds On (Typ) | 20 mOhm | |
| Input Type | Non-Inverting | |
| Features | - | |
| Fault Protection | Current Limiting (Fixed), Over Temperature | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | |
| Supplier Device Package | D2PAK | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AUIPS1021S | |
| Related Links | AUIPS, AUIPS1021S Datasheet, International Rectifier (Infineon Technologies Americas Corp.) Distributor | |
AUIPS1021S Details Description
