Artesyn Embedded Technologies AVD85-48S3V3TL
- Mfg. Part Number
- AVD85-48S3V3TL
- Manufacturer
- Artesyn Embedded Technologies
- Product Category
- DC DC Converters
- Brief Description
- DC/DC CONVERTER 3.3V 85W
- Datasheet Download
- AVD85-48S3V3TL.pdf
Availability of AVD85-48S3V3TL
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 34.15440
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AVD85-48S3V3TL, we specialize in Artesyn Embedded Technologies all series electronic components. AVD85-48S3V3TL can be shipped within 24 hours after order. If you have any demands for AVD85-48S3V3TL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AVD85-48S3V3TL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AVD85-48S3V3TL
| Internal Part Number | EIS-AVD85-48S3V3TL | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 150 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | AVD85 | |
| Packaging | Tray | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 36V | |
| Voltage - Input (Max) | 75V | |
| Voltage - Output 1 | 3.3V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 25A | |
| Power (Watts) - Manufacture Series | 85W | |
| Voltage - Isolation | - | |
| Features | Remote On/Off | |
| Mounting Type | Through Hole | |
| Package / Case | 8-DIP Module, 1/16 Brick | |
| Size / Dimension | 1.30" L x 0.90" W x 0.41" H (33.0mm x 22.9mm x 10.5mm) | |
| Operating Temperature | - | |
| Efficiency | 92% | |
| Power (Watts) - Max | 83W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AVD85-48S3V3TL | |
| Related Links | AVD85-4, AVD85-48S3V3TL Datasheet, Artesyn Embedded Technologies Distributor | |
AVD85-48S3V3TL Details Description
