ASSMANN WSW Components AWLP-14/3.2-T-R
- Mfg. Part Number
- AWLP-14/3.2-T-R
- Manufacturer
- ASSMANN WSW Components
- Product Category
- Rectangular Connectors - Board In, Direct Wire to Board
- Brief Description
- CONN DIP 14POS .1" X .1" TIN
- Datasheet Download
- AWLP-14/3.2-T-R.pdf
Availability of AWLP-14/3.2-T-R
Available Quantity
5052 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.31020
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AWLP-14/3.2-T-R, we specialize in ASSMANN WSW Components all series electronic components. AWLP-14/3.2-T-R can be shipped within 24 hours after order. If you have any demands for AWLP-14/3.2-T-R, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AWLP-14/3.2-T-R Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AWLP-14/3.2-T-R
| Internal Part Number | EIS-AWLP-14/3.2-T-R | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Assmann - IDC Connectors and Cables Cable Assemblies | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 132 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Board In, Direct Wire to Board | |
| Series | - | |
| Packaging | Tray | |
| Connector Type | Ribbon Cable | |
| Number of Positions | 14 | |
| Cable Pitch | 0.050" (1.27mm) | |
| Board-Side Pitch | 0.100" (2.54mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.100" (2.54mm) | |
| Mounting Type | Through Hole | |
| Cable Termination | IDC | |
| Wire Gauge | - | |
| Features | Feed Through | |
| Contact Finish | Tin | |
| Contact Finish Thickness | - | |
| Color | Gray | |
| Number of Positions Loaded | All | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AWLP-14/3.2-T-R | |
| Related Links | AWLP-14, AWLP-14/3.2-T-R Datasheet, ASSMANN WSW Components Distributor | |
AWLP-14/3.2-T-R Details Description
