Microchip Technology AY0438/P
- Mfg. Part Number
- AY0438/P
- Manufacturer
- Microchip Technology
- Product Category
- PMIC - Display Drivers
- Brief Description
- IC LCD DRIVER CMOS 32SEG 40DIP
- Datasheet Download
- AY0438/P.pdf
Availability of AY0438/P
Available Quantity
5957 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.78000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AY0438/P, we specialize in Microchip Technology all series electronic components. AY0438/P can be shipped within 24 hours after order. If you have any demands for AY0438/P, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AY0438/P Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AY0438/P
| Internal Part Number | EIS-AY0438/P | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | Qualification PDIP-28L/40L 21/Oct/2013 Qualification Assembly Site PDIP-28/40L 23/Aug/2013 Assembly Site Transfer 13/May/2015 | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Standard Package | 10 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Display Drivers | |
| Series | - | |
| Packaging | Tube | |
| Display Type | LCD | |
| Configuration | 32 Segment | |
| Interface | Parallel | |
| Digits or Characters | 16 Characters | |
| Current - Supply | 25µA | |
| Voltage - Supply | 3 V ~ 8.5 V | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Through Hole | |
| Package / Case | 40-DIP (0.600", 15.24mm) | |
| Supplier Device Package | 40-PDIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AY0438/P | |
| Related Links | AY04, AY0438/P Datasheet, Microchip Technology Distributor | |
AY0438/P Details Description
