Panasonic Electric Works AYF533065
- Mfg. Part Number
- AYF533065
- Manufacturer
- Panasonic Electric Works
- Product Category
- FFC, FPC (Flat Flexible) Connectors
- Brief Description
- CONN FPC 30POS 0.50MM R/A
- Datasheet Download
- AYF533065.pdf
Availability of AYF533065
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AYF533065, we specialize in Panasonic Electric Works all series electronic components. AYF533065 can be shipped within 24 hours after order. If you have any demands for AYF533065, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AYF533065 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AYF533065
| Internal Part Number | EIS-AYF533065 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | How to Read Date Codes | |
| PCN Obsolescence/ EOL | AYF53yy65 15/Apr/2014 | |
| PCN Design/Specification | AYF53yy65 Specification 17/Jan/2014 | |
| Standard Package | 1,000 | |
| Category | Connectors, Interconnects | |
| Family | FFC, FPC (Flat Flexible) Connectors | |
| Series | Y5BW | |
| Packaging | Tape & Reel (TR) | |
| Flat Flex Type | FPC | |
| Mounting Type | Surface Mount, Right Angle | |
| Connector/Contact Type | Contacts, Top and Bottom | |
| Number of Positions | 30 | |
| Pitch | 0.020" (0.50mm) | |
| Termination | Solder | |
| FFC, FCB Thickness | 0.30mm | |
| Height Above Board | 0.039" (1.00mm) | |
| Locking Feature | Flip Lock, Backlock | |
| Cable End Type | Notched | |
| Contact Material | Copper Alloy | |
| Contact Finish | Gold | |
| Housing Material | Liquid Crystal Polymer (LCP) | |
| Actuator Material | Liquid Crystal Polymer (LCP) | |
| Features | - | |
| Voltage Rating | 50V | |
| Operating Temperature | -55°C ~ 85°C | |
| Material Flammability Rating | UL94 V-0 | |
| Current Rating | 0.5A per Contact | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AYF533065 | |
| Related Links | AYF5, AYF533065 Datasheet, Panasonic Electric Works Distributor | |
AYF533065 Details Description
