ST BAS69-07P6FILM
- Mfg. Part Number
- BAS69-07P6FILM
- Manufacturer
- ST
- Product Category
- Diodes, Rectifiers - Arrays
- Brief Description
- DIODE ARRAY SCHOTTKY 15V SOT666
- Datasheet Download
- BAS69-07P6FILM.pdf
Availability of BAS69-07P6FILM
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of BAS69-07P6FILM, we specialize in ST all series electronic components. BAS69-07P6FILM can be shipped within 24 hours after order. If you have any demands for BAS69-07P6FILM, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- BAS69-07P6FILM Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
BAS69-07P6FILM
| Internal Part Number | EIS-BAS69-07P6FILM | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Arrays | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Diode Configuration | 2 Independent | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 15V | |
| Current - Average Rectified (Io) (per Diode) | 10mA (DC) | |
| Voltage - Forward (Vf) (Max) @ If | 570mV @ 10mA | |
| Speed | Small Signal =< 200mA (Io), Any Speed | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 230nA @ 15V | |
| Mounting Type | Surface Mount | |
| Package / Case | SOT-563, SOT-666 | |
| Supplier Device Package | SOT-666 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | BAS69-07P6FILM | |
| Related Links | BAS69-0, BAS69-07P6FILM Datasheet, ST Distributor | |
