Silicon Labs C8051F006
- Mfg. Part Number
- C8051F006
- Manufacturer
- Silicon Labs
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC 8051 MCU 32K FLASH 48TQFP
- Datasheet Download
- C8051F006.pdf
Availability of C8051F006
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of C8051F006, we specialize in Silicon Labs all series electronic components. C8051F006 can be shipped within 24 hours after order. If you have any demands for C8051F006, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- C8051F006 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
C8051F006
| Internal Part Number | EIS-C8051F006 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 250 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | C8051F00x | |
| Packaging | Tray | |
| Core Processor | 8051 | |
| Core Size | 8-Bit | |
| Speed | 25MHz | |
| Connectivity | SMBus (2-Wire/I²C), SPI, UART/USART | |
| Peripherals | Brown-out Detect/Reset, POR, PWM, Temp Sensor, WDT | |
| Number of I/O | 16 | |
| Program Memory Size | 32KB (32K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 2.25K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2.7 V ~ 3.6 V | |
| Data Converters | A/D 8x12b, D/A 2x12b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 48-TQFP | |
| Supplier Device Package | 48-QFP (7x7) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | C8051F006 | |
| Related Links | C805, C8051F006 Datasheet, Silicon Labs Distributor | |
C8051F006 Details Description
