Harwin Inc. C90-3102R10SL-4S
- Mfg. Part Number
- C90-3102R10SL-4S
- Manufacturer
- Harwin Inc.
- Product Category
- Circular Connectors
- Brief Description
- CONN RCPT PNL MNT 2POS W/SKT
- Datasheet Download
- C90-3102R10SL-4S.pdf
Availability of C90-3102R10SL-4S
Available Quantity
5091 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 4.35500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of C90-3102R10SL-4S, we specialize in Harwin Inc. all series electronic components. C90-3102R10SL-4S can be shipped within 24 hours after order. If you have any demands for C90-3102R10SL-4S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- C90-3102R10SL-4S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
C90-3102R10SL-4S
| Internal Part Number | EIS-C90-3102R10SL-4S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | C90 | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 2 | |
| Shell Size - Insert | 10SL-4 | |
| Shell Size, MIL | - | |
| Mounting Type | Panel Mount, Flange | |
| Termination | Solder Cup | |
| Fastening Type | Threaded | |
| Orientation | Keyed | |
| Ingress Protection | IP67 - Dust Tight, Waterproof | |
| Shell Material, Finish | Aluminum, Zinc Plated, Black | |
| Contact Finish | Silver | |
| Features | - | |
| Contact Finish Thickness | - | |
| Current Rating | 13A | |
| Voltage - Rated | 500VAC, 700VDC | |
| Operating Temperature | -55°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | C90-3102R10SL-4S | |
| Related Links | C90-3102, C90-3102R10SL-4S Datasheet, Harwin Inc. Distributor | |
