Texas Instruments CD4086BNSRG4
- Mfg. Part Number
- CD4086BNSRG4
- Manufacturer
- Texas Instruments
- Product Category
- Logic - Gates and Inverters - Multi-Function, Configurable
- Brief Description
- IC EXPND AND-ORINV GATE 14SO
- Datasheet Download
- CD4086BNSRG4.pdf
Availability of CD4086BNSRG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CD4086BNSRG4, we specialize in Texas Instruments all series electronic components. CD4086BNSRG4 can be shipped within 24 hours after order. If you have any demands for CD4086BNSRG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CD4086BNSRG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CD4086BNSRG4
| Internal Part Number | EIS-CD4086BNSRG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Gates and Inverters - Multi-Function, Configurable | |
| Series | 4000B | |
| Packaging | Tape & Reel (TR) | |
| Logic Type | AND/OR/INVERT Gate | |
| Number of Circuits | 1 | |
| Number of Inputs | 8 Input (2, 2, 2, 2) | |
| Schmitt Trigger Input | No | |
| Output Type | Single-Ended | |
| Current - Output High, Low | 6.8mA, 6.8mA | |
| Voltage - Supply | 3 V ~ 18 V | |
| Operating Temperature | -55°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 14-SOIC (0.209", 5.30mm Width) | |
| Supplier Device Package | 14-SO | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CD4086BNSRG4 | |
| Related Links | CD4086, CD4086BNSRG4 Datasheet, Texas Instruments Distributor | |
