3M CP2-HSB125-2
- Mfg. Part Number
- CP2-HSB125-2
- Manufacturer
- 3M
- Product Category
- Backplane Connectors - Housings
- Brief Description
- CONN SOCKET SHROUD 125POS 2MM
- Datasheet Download
- CP2-HSB125-2.pdf
Availability of CP2-HSB125-2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.48000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CP2-HSB125-2, we specialize in 3M all series electronic components. CP2-HSB125-2 can be shipped within 24 hours after order. If you have any demands for CP2-HSB125-2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CP2-HSB125-2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CP2-HSB125-2
| Internal Part Number | EIS-CP2-HSB125-2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 672 | |
| Category | Connectors, Interconnects | |
| Family | Backplane Connectors - Housings | |
| Series | MetPak™ CP2 | |
| Packaging | Bulk | |
| Connector Type | Shroud for Male Pins | |
| Connector Style | - | |
| Number of Positions | 125 | |
| Pitch | 0.079" (2.00mm) | |
| Number of Rows | 5 | |
| Mounting Type | Through Hole | |
| Connector Usage | - | |
| Features | - | |
| Color | - | |
| Note | Contacts Not Provided | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CP2-HSB125-2 | |
| Related Links | CP2-HS, CP2-HSB125-2 Datasheet, 3M Distributor | |
CP2-HSB125-2 Details Description
