ON Semiconductor CSPEMI307AG
- Mfg. Part Number
- CSPEMI307AG
- Manufacturer
- ON Semiconductor
- Product Category
- EMI/RFI Filters (LC, RC Networks)
- Brief Description
- IC EMI FILTER ARRAY 4CH 15CSP
- Datasheet Download
- CSPEMI307AG.pdf
Availability of CSPEMI307AG
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.24000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CSPEMI307AG, we specialize in ON Semiconductor all series electronic components. CSPEMI307AG can be shipped within 24 hours after order. If you have any demands for CSPEMI307AG, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CSPEMI307AG Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CSPEMI307AG
| Internal Part Number | EIS-CSPEMI307AG | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,500 | |
| Category | Filters | |
| Family | EMI/RFI Filters (LC, RC Networks) | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Low Pass | |
| Technology | RC (Pi) | |
| Number of Channels | 4 | |
| Center / Cutoff Frequency | 64MHz (Cutoff) | |
| Attenuation Value | 30dB @ 800MHz ~ 2.7GHz | |
| Resistance - Channel (Ohms) | 100 | |
| Current | - | |
| Values | R = 100 Ohms, C = 30pF | |
| ESD Protection | Yes | |
| Filter Order | 2nd | |
| Applications | USB | |
| Package / Case | 15-UFBGA, WLCSP | |
| Size / Dimension | 0.117" L x 0.052" W (2.96mm x 1.33mm) | |
| Height | 0.026" (0.65mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CSPEMI307AG | |
| Related Links | CSPEM, CSPEMI307AG Datasheet, ON Semiconductor Distributor | |
CSPEMI307AG Details Description
