Cypress Semiconductor CY8C20121-SX1IT
- Mfg. Part Number
- CY8C20121-SX1IT
- Manufacturer
- Cypress Semiconductor
- Product Category
- Capacitive Touch Sensors, Proximity Sensor ICs
- Brief Description
- IC CAPSENSE EXP 8-SOIC
- Datasheet Download
- CY8C20121-SX1IT.pdf
Availability of CY8C20121-SX1IT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.65610
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CY8C20121-SX1IT, we specialize in Cypress Semiconductor all series electronic components. CY8C20121-SX1IT can be shipped within 24 hours after order. If you have any demands for CY8C20121-SX1IT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CY8C20121-SX1IT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CY8C20121-SX1IT
| Internal Part Number | EIS-CY8C20121-SX1IT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | CapSense Sensing Technology | |
| PCN Assembly/Origin | Copper Wire Bonds/Transfer 14/Jun/2013 Qualification Tape Supplier 18/Mar/2014 GSMC Manufacture Merger 15/May/2014 Wafer Test Site Addition 29/Jun/2015 | |
| PCN Packaging | New Tray and TR Materials 13/Dec/2013 | |
| PCN Other | Multiple Updates 27/Mar/2015 | |
| Standard Package | 2,500 | |
| Category | Sensors, Transducers | |
| Family | Capacitive Touch Sensors, Proximity Sensor ICs | |
| Series | CapSense® Express™ | |
| Packaging | Tape & Reel (TR) | |
| Type | Buttons | |
| Proximity Detection | No | |
| Number of Inputs | Up to 2 | |
| LED Driver Channels | Up to 2 | |
| Interface | I²C | |
| Resolution | - | |
| Voltage - Supply | 2.4 V ~ 5.25 V | |
| Current - Supply | 1.5mA | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CY8C20121-SX1IT | |
| Related Links | CY8C201, CY8C20121-SX1IT Datasheet, Cypress Semiconductor Distributor | |
CY8C20121-SX1IT Details Description
