Cypress Semiconductor CY8C21534-24PVXIT
- Mfg. Part Number
- CY8C21534-24PVXIT
- Manufacturer
- Cypress Semiconductor
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 8K FLASH 512B SRAM 28SSOP
- Datasheet Download
- CY8C21534-24PVXIT.pdf
Availability of CY8C21534-24PVXIT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.70100
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CY8C21534-24PVXIT, we specialize in Cypress Semiconductor all series electronic components. CY8C21534-24PVXIT can be shipped within 24 hours after order. If you have any demands for CY8C21534-24PVXIT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CY8C21534-24PVXIT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CY8C21534-24PVXIT
| Internal Part Number | EIS-CY8C21534-24PVXIT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Featured Product | CapSense Sensing Technology | |
| PCN Assembly/Origin | Qualification Tape Supplier 18/Mar/2014 GSMC Manufacture Merger 15/May/2014 Wafer Test Site Addition 29/Jun/2015 | |
| PCN Packaging | New Tray and TR Materials 13/Dec/2013 | |
| PCN Other | Multiple Updates 27/Mar/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | PSOC®1 CY8C21xxx | |
| Packaging | Tape & Reel (TR) | |
| Core Processor | M8C | |
| Core Size | 8-Bit | |
| Speed | 24MHz | |
| Connectivity | I²C, SPI, UART/USART | |
| Peripherals | POR, PWM, WDT | |
| Number of I/O | 24 | |
| Program Memory Size | 8KB (8K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 512 x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2.4 V ~ 5.25 V | |
| Data Converters | A/D 28x8b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 28-SSOP (0.209", 5.30mm Width) | |
| Supplier Device Package | 28-SSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CY8C21534-24PVXIT | |
| Related Links | CY8C2153, CY8C21534-24PVXIT Datasheet, Cypress Semiconductor Distributor | |
CY8C21534-24PVXIT Details Description
