FFF DBO13W3S743M30LF
- Mfg. Part Number
- DBO13W3S743M30LF
- Manufacturer
- FFF
- Product Category
- D-Sub Connectors
- Brief Description
- D-Sub Connector Receptacle, Female Sockets 13 (10 + 3 Power) Position Through Hole, Right Angle Solder
- Datasheet Download
- DBO13W3S743M30LF.pdf
Availability of DBO13W3S743M30LF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 18.68004
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DBO13W3S743M30LF, we specialize in FFF all series electronic components. DBO13W3S743M30LF can be shipped within 24 hours after order. If you have any demands for DBO13W3S743M30LF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DBO13W3S743M30LF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DBO13W3S743M30LF
| Internal Part Number | EIS-DBO13W3S743M30LF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 80 | |
| Category | Connectors, Interconnects | |
| Family | D-Sub Connectors | |
| Series | DW | |
| Packaging | Tray | |
| Connector Style | D-Sub, Combo | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 13 (10 + 3 Power) | |
| Number of Rows | 2 | |
| Shell Size, Connector Layout | 3 (DB, B) - 13C3, 13W3 | |
| Contact Type | Signal and Power | |
| Mounting Type | Through Hole, Right Angle | |
| Flange Feature | Board Side (4-40) | |
| Termination | Solder | |
| Features | Mounting Brackets | |
| Shell Material, Finish | Steel, Tin Plated | |
| Contact Finish | Gold | |
| Contact Finish Thickness | - | |
| Ingress Protection | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Voltage Rating | 300V | |
| Current Rating | 30A, 7.5A | |
| Housing Material | Thermoplastic | |
| Color | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DBO13W3S743M30LF | |
| Related Links | DBO13W3S, DBO13W3S743M30LF Datasheet, FFF Distributor | |
DBO13W3S743M30LF Details Description
