ITT Cannon, LLC DCMC-8C8S-J-A197
- Mfg. Part Number
- DCMC-8C8S-J-A197
- Manufacturer
- ITT Cannon, LLC
- Product Category
- D-Sub Connectors
- Brief Description
- D-Sub Connector Receptacle, Female Sockets 8 (Coax) Position Panel Mount, Through Hole, Right Angle Solder
- Datasheet Download
- DCMC-8C8S-J-A197.pdf
Availability of DCMC-8C8S-J-A197
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 55.07980
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DCMC-8C8S-J-A197, we specialize in ITT Cannon, LLC all series electronic components. DCMC-8C8S-J-A197 can be shipped within 24 hours after order. If you have any demands for DCMC-8C8S-J-A197, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DCMC-8C8S-J-A197 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DCMC-8C8S-J-A197
| Internal Part Number | EIS-DCMC-8C8S-J-A197 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | D-Sub Connectors | |
| Series | Combo D®, D*M | |
| Packaging | Bulk | |
| Connector Style | D-Sub, Combo | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 8 (Coax) | |
| Number of Rows | 1 | |
| Shell Size, Connector Layout | 4 (DC, C) - 8W8 | |
| Contact Type | Coax | |
| Mounting Type | Panel Mount, Through Hole, Right Angle | |
| Flange Feature | Housing/Shell (4-40) | |
| Termination | Solder | |
| Features | Board Lock, Mounting Brackets, Shielded | |
| Shell Material, Finish | Steel, Tin-Lead Plated | |
| Contact Finish | Gold | |
| Contact Finish Thickness | Flash | |
| Ingress Protection | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Voltage Rating | - | |
| Current Rating | 5A | |
| Housing Material | Polyester | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DCMC-8C8S-J-A197 | |
| Related Links | DCMC-8C8, DCMC-8C8S-J-A197 Datasheet, ITT Cannon, LLC Distributor | |
DCMC-8C8S-J-A197 Details Description
