Hirose Electric Co Ltd DF1BZ-20DP-2.5DS
- Mfg. Part Number
- DF1BZ-20DP-2.5DS
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- CONN HEADER 20POS 2.5MM R/A TIN
- Datasheet Download
- DF1BZ-20DP-2.5DS.pdf
Availability of DF1BZ-20DP-2.5DS
Available Quantity
5220 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.49300
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DF1BZ-20DP-2.5DS, we specialize in Hirose Electric Co Ltd all series electronic components. DF1BZ-20DP-2.5DS can be shipped within 24 hours after order. If you have any demands for DF1BZ-20DP-2.5DS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DF1BZ-20DP-2.5DS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DF1BZ-20DP-2.5DS
| Internal Part Number | EIS-DF1BZ-20DP-2.5DS | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Wire-to-Board Connector | |
| Standard Package | 100 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | DF1B | |
| Packaging | Bulk | |
| Contact Type | Male Pin | |
| Connector Type | Header, Shrouded | |
| Number of Positions | 20 | |
| Number of Positions Loaded | All | |
| Pitch | 0.098" (2.50mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.098" (2.50mm) | |
| Contact Mating Length | 0.177" (4.50mm) | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Solder | |
| Fastening Type | - | |
| Features | - | |
| Contact Finish | Tin | |
| Contact Finish Thickness | - | |
| Color | White | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DF1BZ-20DP-2.5DS | |
| Related Links | DF1BZ-20, DF1BZ-20DP-2.5DS Datasheet, Hirose Electric Co Ltd Distributor | |
