Maxim Integrated DS1669-10+
- Mfg. Part Number
- DS1669-10+
- Manufacturer
- Maxim Integrated
- Product Category
- Data Acquisition - Digital Potentiometers
- Brief Description
- IC RHEOSTAT DALLASTAT 10K 8-DIP
- Datasheet Download
- DS1669-10+.pdf
Availability of DS1669-10+
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DS1669-10+, we specialize in Maxim Integrated all series electronic components. DS1669-10+ can be shipped within 24 hours after order. If you have any demands for DS1669-10+, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DS1669-10+ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DS1669-10+
| Internal Part Number | EIS-DS1669-10+ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Digitally-Controlled Phase Shift Using the DS1669 | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Digital Potentiometers | |
| Series | Dallastat™ | |
| Packaging | Tube | |
| Taper | Linear | |
| Configuration | Potentiometer | |
| Number of Circuits | 1 | |
| Number of Taps | 64 | |
| Resistance (Ohms) | 10k | |
| Interface | Up/Down (UP, DN) | |
| Memory Type | Non-Volatile | |
| Voltage - Supply | 4.5 V ~ 8 V | |
| Features | - | |
| Tolerance | ±20% | |
| Temperature Coefficient (Typ) | 750 ppm/°C | |
| Resistance - Wiper (Ohms) (Typ) | 400 | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 8-DIP (0.300", 7.62mm) | |
| Supplier Device Package | 8-PDIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DS1669-10+ | |
| Related Links | DS166, DS1669-10+ Datasheet, Maxim Integrated Distributor | |
DS1669-10+ Details Description
