Microchip Technology DSC1121AI2-025.0006T
- Mfg. Part Number
- DSC1121AI2-025.0006T
- Manufacturer
- Microchip Technology
- Product Category
- Oscillators
- Brief Description
- OSC MEMS 25.0006MHZ CMOS SMD
- Datasheet Download
- DSC1121AI2-025.0006T.pdf
Availability of DSC1121AI2-025.0006T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.00050
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DSC1121AI2-025.0006T, we specialize in Microchip Technology all series electronic components. DSC1121AI2-025.0006T can be shipped within 24 hours after order. If you have any demands for DSC1121AI2-025.0006T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DSC1121AI2-025.0006T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DSC1121AI2-025.0006T
| Internal Part Number | EIS-DSC1121AI2-025.0006T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Clock System Design High-Speed PECL and LVPECL Termination | |
| Standard Package | 1,000 | |
| Category | Crystals and Oscillators | |
| Family | Oscillators | |
| Series | DSC1121 | |
| Packaging | Tape & Reel (TR) | |
| Type | MEMS (Silicon) | |
| Frequency | 25.0006MHz | |
| Function | Tri-State (Output Enable) | |
| Output | CMOS | |
| Voltage - Supply | 2.25 V ~ 3.6 V | |
| Frequency Stability | ±25ppm | |
| Operating Temperature | -40°C ~ 85°C | |
| Current - Supply (Max) | 35mA | |
| Ratings | AEC-Q100 | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.276" L x 0.197" W (7.00mm x 5.00mm) | |
| Height | 0.035" (0.90mm) | |
| Package / Case | 6-SMD, No Leads, Exposed Pad | |
| Current - Supply (Disable) (Max) | 22mA | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DSC1121AI2-025.0006T | |
| Related Links | DSC1121AI2, DSC1121AI2-025.0006T Datasheet, Microchip Technology Distributor | |
DSC1121AI2-025.0006T Details Description
