ECS Inc. International ECS-2100A-035
- Mfg. Part Number
- ECS-2100A-035
- Manufacturer
- ECS Inc. International
- Product Category
- Oscillators
- Brief Description
- OSC XO 3.579545MHZ HCMOS TTL PC
- Datasheet Download
- ECS-2100A-035.pdf
Availability of ECS-2100A-035
Available Quantity
6586 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.10500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ECS-2100A-035, we specialize in ECS Inc. International all series electronic components. ECS-2100A-035 can be shipped within 24 hours after order. If you have any demands for ECS-2100A-035, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ECS-2100A-035 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ECS-2100A-035
| Internal Part Number | EIS-ECS-2100A-035 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 40 | |
| Category | Crystals and Oscillators | |
| Family | Oscillators | |
| Series | ECS-2100 | |
| Packaging | Bulk | |
| Type | XO (Standard) | |
| Frequency | 3.579545MHz | |
| Function | - | |
| Output | HCMOS, TTL | |
| Voltage - Supply | 5V | |
| Frequency Stability | ±100ppm | |
| Operating Temperature | 0°C ~ 70°C | |
| Current - Supply (Max) | 25mA | |
| Ratings | - | |
| Mounting Type | Through Hole | |
| Size / Dimension | 0.520" L x 0.520" W (13.20mm x 13.20mm) | |
| Height | 0.213" (5.40mm) | |
| Package / Case | 8-DIP, 4 Leads (Half Size, Metal Can) | |
| Current - Supply (Disable) (Max) | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ECS-2100A-035 | |
| Related Links | ECS-21, ECS-2100A-035 Datasheet, ECS Inc. International Distributor | |
ECS-2100A-035 Details Description
