Panasonic Electronic Components ERJ-14NF2320U
- Mfg. Part Number
- ERJ-14NF2320U
- Manufacturer
- Panasonic Electronic Components
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 232 OHM 1% 1/2W 1210
- Datasheet Download
- ERJ-14NF2320U.pdf
Availability of ERJ-14NF2320U
Available Quantity
15020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.02117
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ERJ-14NF2320U, we specialize in Panasonic Electronic Components all series electronic components. ERJ-14NF2320U can be shipped within 24 hours after order. If you have any demands for ERJ-14NF2320U, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ERJ-14NF2320U Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ERJ-14NF2320U
| Internal Part Number | EIS-ERJ-14NF2320U | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 5,000 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | ERJ | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 232 | |
| Tolerance | ±1% | |
| Power (Watts) | 0.5W, 1/2W | |
| Composition | Thick Film | |
| Features | Automotive AEC-Q200 | |
| Temperature Coefficient | ±100ppm/°C | |
| Operating Temperature | -55°C ~ 155°C | |
| Package / Case | 1210 (3225 Metric) | |
| Supplier Device Package | 1210 | |
| Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.50mm) | |
| Height | 0.028" (0.70mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ERJ-14NF2320U | |
| Related Links | ERJ-14, ERJ-14NF2320U Datasheet, Panasonic Electronic Components Distributor | |
ERJ-14NF2320U Details Description
