Fairchild Semiconductor FQP9N25CTSTU
- Mfg. Part Number
- FQP9N25CTSTU
- Manufacturer
- Fairchild Semiconductor
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 250V 8.8A TO-220
- Datasheet Download
- FQP9N25CTSTU.pdf
Availability of FQP9N25CTSTU
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FQP9N25CTSTU, we specialize in Fairchild Semiconductor all series electronic components. FQP9N25CTSTU can be shipped within 24 hours after order. If you have any demands for FQP9N25CTSTU, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FQP9N25CTSTU Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FQP9N25CTSTU
| Internal Part Number | EIS-FQP9N25CTSTU | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | QFET® | |
| Packaging | Tube | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 250V | |
| Current - Continuous Drain (Id) @ 25°C | 8.8A (Tc) | |
| Rds On (Max) @ Id, Vgs | 430 mOhm @ 4.4A, 10V | |
| Vgs(th) (Max) @ Id | 4V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 35nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 710pF @ 25V | |
| Power - Max | 74W | |
| Mounting Type | Through Hole | |
| Package / Case | TO-220-3 | |
| Supplier Device Package | TO-220 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FQP9N25CTSTU | |
| Related Links | FQP9N2, FQP9N25CTSTU Datasheet, Fairchild Semiconductor Distributor | |
FQP9N25CTSTU Details Description
