Samtec, Inc. FTSH-120-01-F-D-K
- Mfg. Part Number
- FTSH-120-01-F-D-K
- Manufacturer
- Samtec, Inc.
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- CONN HEADER 40POS DUAL .05" VERT
- Datasheet Download
- FTSH-120-01-F-D-K.pdf
Availability of FTSH-120-01-F-D-K
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.98000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FTSH-120-01-F-D-K, we specialize in Samtec, Inc. all series electronic components. FTSH-120-01-F-D-K can be shipped within 24 hours after order. If you have any demands for FTSH-120-01-F-D-K, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FTSH-120-01-F-D-K Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FTSH-120-01-F-D-K
| Internal Part Number | EIS-FTSH-120-01-F-D-K | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | FTSH | |
| Packaging | Tube | |
| Contact Type | Male Pin | |
| Connector Type | Header, Shrouded | |
| Number of Positions | 40 | |
| Number of Positions Loaded | All | |
| Pitch | 0.050" (1.27mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.050" (1.27mm) | |
| Contact Mating Length | 0.120" (3.05mm) | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Fastening Type | - | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 3µin (0.08µm) | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FTSH-120-01-F-D-K | |
| Related Links | FTSH-120, FTSH-120-01-F-D-K Datasheet, Samtec, Inc. Distributor | |
FTSH-120-01-F-D-K Details Description
