Hirose Electric Co Ltd FX8C-60S-SV5(93)
- Mfg. Part Number
- FX8C-60S-SV5(93)
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine
- Brief Description
- CONN RECEPT 60POS .6MM GOLD SMD
- Datasheet Download
- FX8C-60S-SV5(93).pdf
Availability of FX8C-60S-SV5(93)
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.89000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FX8C-60S-SV5(93), we specialize in Hirose Electric Co Ltd all series electronic components. FX8C-60S-SV5(93) can be shipped within 24 hours after order. If you have any demands for FX8C-60S-SV5(93), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FX8C-60S-SV5(93) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FX8C-60S-SV5(93)
| Internal Part Number | EIS-FX8C-60S-SV5(93) | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 500 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine | |
| Series | FunctionMax™ FX8C | |
| Packaging | Tape & Reel (TR) | |
| Connector Type | Receptacle, Center Strip Contacts | |
| Number of Positions | 60 | |
| Pitch | 0.023" (0.60mm) | |
| Number of Rows | 2 | |
| Mounting Type | Surface Mount | |
| Features | Board Guide | |
| Contact Finish | Gold | |
| Contact Finish Thickness | - | |
| Mated Stacking Heights | 10mm, 11mm, 12mm, 14mm, 16mm | |
| Height Above Board | 0.352" (8.95mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FX8C-60S-SV5(93) | |
| Related Links | FX8C-60S, FX8C-60S-SV5(93) Datasheet, Hirose Electric Co Ltd Distributor | |
FX8C-60S-SV5(93) Details Description
