Sullins Connector Solutions GCB100DHRN
- Mfg. Part Number
- GCB100DHRN
- Manufacturer
- Sullins Connector Solutions
- Product Category
- Card Edge Connectors - Edgeboard Connectors
- Brief Description
- CONN CARD EXTEND 200PS .050" SLD
- Datasheet Download
- GCB100DHRN.pdf
Availability of GCB100DHRN
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 15.14700
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of GCB100DHRN, we specialize in Sullins Connector Solutions all series electronic components. GCB100DHRN can be shipped within 24 hours after order. If you have any demands for GCB100DHRN, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- GCB100DHRN Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
GCB100DHRN
| Internal Part Number | EIS-GCB100DHRN | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10 | |
| Category | Connectors, Interconnects | |
| Family | Card Edge Connectors - Edgeboard Connectors | |
| Series | - | |
| Packaging | Tube | |
| Card Type | Non Specified - Dual Edge | |
| Gender | Female | |
| Number of Positions/Bay/Row | 100 | |
| Number of Positions | 200 | |
| Card Thickness | 0.062" (1.57mm) | |
| Number of Rows | 2 | |
| Pitch | 0.050" (1.27mm) | |
| Features | Card Extender | |
| Mounting Type | Board Edge, Straddle Mount | |
| Termination | Solder | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Contact Type | Hairpin Bellows | |
| Color | Black | |
| Flange Feature | - | |
| Operating Temperature | -65°C ~ 125°C | |
| Material - Insulation | Polyamide (PA9T) | |
| Read Out | Dual | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | GCB100DHRN | |
| Related Links | GCB10, GCB100DHRN Datasheet, Sullins Connector Solutions Distributor | |
