Vishay Semiconductor/Diodes Division GDZ9V1B-HG3-18
- Mfg. Part Number
- GDZ9V1B-HG3-18
- Manufacturer
- Vishay Semiconductor/Diodes Division
- Product Category
- Diodes - Zener - Single
- Brief Description
- DIODE ZENER 9.1V 200MW SOD323
- Datasheet Download
- GDZ9V1B-HG3-18.pdf
Availability of GDZ9V1B-HG3-18
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.04800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of GDZ9V1B-HG3-18, we specialize in Vishay Semiconductor/Diodes Division all series electronic components. GDZ9V1B-HG3-18 can be shipped within 24 hours after order. If you have any demands for GDZ9V1B-HG3-18, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- GDZ9V1B-HG3-18 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
GDZ9V1B-HG3-18
| Internal Part Number | EIS-GDZ9V1B-HG3-18 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes - Zener - Single | |
| Series | Automotive, AEC-Q101 | |
| Packaging | Tape & Reel (TR) | |
| Voltage - Zener (Nom) (Vz) | 9.1V | |
| Tolerance | ±2% | |
| Power - Max | 200mW | |
| Impedance (Max) (Zzt) | 30 Ohm | |
| Current - Reverse Leakage @ Vr | 500nA @ 6V | |
| Voltage - Forward (Vf) (Max) @ If | - | |
| Operating Temperature | -55°C ~ 150°C | |
| Mounting Type | Surface Mount | |
| Package / Case | SC-76, SOD-323 | |
| Supplier Device Package | SOD-323 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | GDZ9V1B-HG3-18 | |
| Related Links | GDZ9V1B, GDZ9V1B-HG3-18 Datasheet, Vishay Semiconductor/Diodes Division Distributor | |
GDZ9V1B-HG3-18 Details Description
