Renesas Electronics America HD64F3670FP
- Mfg. Part Number
- HD64F3670FP
- Manufacturer
- Renesas Electronics America
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 16BIT 8KB FLASH 64LQFP
- Datasheet Download
- HD64F3670FP.pdf
Availability of HD64F3670FP
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HD64F3670FP, we specialize in Renesas Electronics America all series electronic components. HD64F3670FP can be shipped within 24 hours after order. If you have any demands for HD64F3670FP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HD64F3670FP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HD64F3670FP
| Internal Part Number | EIS-HD64F3670FP | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | H8® H8/300H Tiny | |
| Packaging | Tray | |
| Core Processor | H8/300H | |
| Core Size | 16-Bit | |
| Speed | 16MHz | |
| Connectivity | SCI | |
| Peripherals | PWM, WDT | |
| Number of I/O | 26 | |
| Program Memory Size | 8KB (8K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 2K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 3 V ~ 5.5 V | |
| Data Converters | A/D 4x10b | |
| Oscillator Type | External | |
| Operating Temperature | -20°C ~ 75°C | |
| Package / Case | 64-LQFP | |
| Supplier Device Package | 64-LQFP (10x10) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HD64F3670FP | |
| Related Links | HD64F, HD64F3670FP Datasheet, Renesas Electronics America Distributor | |
