Vishay/Dale IMC1812RQ561K
- Mfg. Part Number
- IMC1812RQ561K
- Manufacturer
- Vishay/Dale
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 560UH 50MA 30 OHM SMD
- Datasheet Download
- IMC1812RQ561K.pdf
Availability of IMC1812RQ561K
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.37910
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IMC1812RQ561K, we specialize in Vishay/Dale all series electronic components. IMC1812RQ561K can be shipped within 24 hours after order. If you have any demands for IMC1812RQ561K, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IMC1812RQ561K Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IMC1812RQ561K
| Internal Part Number | EIS-IMC1812RQ561K | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | IMC-1812 | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Ferrite | |
| Inductance | 560µH | |
| Tolerance | ±10% | |
| Current Rating | 50mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 30 Ohm Max | |
| Q @ Freq | 30 @ 790kHz | |
| Frequency - Self Resonant | 3MHz | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 790kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 1812 (4532 Metric) | |
| Size / Dimension | 0.177" L x 0.126" W (4.50mm x 3.20mm) | |
| Height - Seated (Max) | 0.134" (3.40mm) | |
| Supplier Device Package | 1812 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IMC1812RQ561K | |
| Related Links | IMC181, IMC1812RQ561K Datasheet, Vishay/Dale Distributor | |
IMC1812RQ561K Details Description
