International Rectifier (Infineon Technologies Americas Corp.) IRS2001MPBF
- Mfg. Part Number
- IRS2001MPBF
- Manufacturer
- International Rectifier (Infineon Technologies Americas Corp.)
- Product Category
- PMIC - Gate Drivers
- Brief Description
- IC DRIVER HIGH/LOW SIDE 16MLPQ
- Datasheet Download
- IRS2001MPBF.pdf
Availability of IRS2001MPBF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IRS2001MPBF, we specialize in International Rectifier (Infineon Technologies Americas Corp.) all series electronic components. IRS2001MPBF can be shipped within 24 hours after order. If you have any demands for IRS2001MPBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IRS2001MPBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IRS2001MPBF
| Internal Part Number | EIS-IRS2001MPBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | MLPQ Materials 26/Feb/2013 | |
| Standard Package | 92 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Gate Drivers | |
| Series | - | |
| Packaging | Tube | |
| Configuration | High and Low Side, Synchronous | |
| Input Type | Non-Inverting | |
| Delay Time | 160ns | |
| Current - Peak | 290mA | |
| Number of Configurations | 1 | |
| Number of Outputs | 2 | |
| High Side Voltage - Max (Bootstrap) | 200V | |
| Voltage - Supply | 10 V ~ 20 V | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 16-VFQFN Exposed Pad | |
| Supplier Device Package | 16-MLPQ (4x4) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IRS2001MPBF | |
| Related Links | IRS20, IRS2001MPBF Datasheet, International Rectifier (Infineon Technologies Americas Corp.) Distributor | |
