Vishay/Dale ISC1210SY22NM
- Mfg. Part Number
- ISC1210SY22NM
- Manufacturer
- Vishay/Dale
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 22NH 640MA 150 MOHM
- Datasheet Download
- ISC1210SY22NM.pdf
Availability of ISC1210SY22NM
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.31960
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ISC1210SY22NM, we specialize in Vishay/Dale all series electronic components. ISC1210SY22NM can be shipped within 24 hours after order. If you have any demands for ISC1210SY22NM, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ISC1210SY22NM Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ISC1210SY22NM
| Internal Part Number | EIS-ISC1210SY22NM | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | ISC-1210 | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Non-Magnetic | |
| Inductance | 22nH | |
| Tolerance | ±20% | |
| Current Rating | 640mA | |
| Current - Saturation | - | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 150 mOhm Max | |
| Q @ Freq | 45 @ 50MHz | |
| Frequency - Self Resonant | 1GHz | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 50MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 1210 (3225 Metric) | |
| Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.49mm) | |
| Height - Seated (Max) | 0.095" (2.41mm) | |
| Supplier Device Package | 1210 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ISC1210SY22NM | |
| Related Links | ISC121, ISC1210SY22NM Datasheet, Vishay/Dale Distributor | |
ISC1210SY22NM Details Description
