Intersil ISL6551IRZ
- Mfg. Part Number
- ISL6551IRZ
- Manufacturer
- Intersil
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Controllers
- Brief Description
- IC REG CTRLR FLYBACK PWM 28-QFN
- Datasheet Download
- ISL6551IRZ.pdf
Availability of ISL6551IRZ
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ISL6551IRZ, we specialize in Intersil all series electronic components. ISL6551IRZ can be shipped within 24 hours after order. If you have any demands for ISL6551IRZ, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ISL6551IRZ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ISL6551IRZ
| Internal Part Number | EIS-ISL6551IRZ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Controllers | |
| Series | - | |
| Packaging | Tube | |
| Number of Outputs | 6 | |
| Frequency - Max | 1MHz | |
| Duty Cycle | 50% | |
| Voltage - Supply | 10.8 V ~ 13.2 V | |
| Buck | No | |
| Boost | No | |
| Flyback | Yes | |
| Inverting | No | |
| Doubler | No | |
| Divider | No | |
| Cuk | No | |
| Isolated | No | |
| Operating Temperature | 0°C ~ 85°C | |
| Package / Case | 28-VQFN Exposed Pad | |
| Supplier Device Package | 28-QFN (6x6) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ISL6551IRZ | |
| Related Links | ISL65, ISL6551IRZ Datasheet, Intersil Distributor | |
