Souriau Connection Technology JBXFD2G18MCSDSR
- Mfg. Part Number
- JBXFD2G18MCSDSR
- Manufacturer
- Souriau Connection Technology
- Product Category
- Circular Connectors
- Brief Description
- CONN PLUG 18POS STR INLINE CRIMP
- Datasheet Download
- JBXFD2G18MCSDSR.pdf
Availability of JBXFD2G18MCSDSR
Available Quantity
5034 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 52.40300
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of JBXFD2G18MCSDSR, we specialize in Souriau Connection Technology all series electronic components. JBXFD2G18MCSDSR can be shipped within 24 hours after order. If you have any demands for JBXFD2G18MCSDSR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- JBXFD2G18MCSDSR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
JBXFD2G18MCSDSR
| Internal Part Number | EIS-JBXFD2G18MCSDSR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | JBX Series Push Pull Connectors | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | JBX | |
| Packaging | Bulk | |
| Connector Type | Plug, Male Pins | |
| Number of Positions | 18 | |
| Shell Size - Insert | 2 | |
| Shell Size, MIL | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Crimp | |
| Fastening Type | Push-Pull | |
| Orientation | G | |
| Ingress Protection | IP40 | |
| Shell Material, Finish | Brass, Chrome over Nickel | |
| Contact Finish | Gold | |
| Features | Cable Clamp, Shielded | |
| Contact Finish Thickness | 19.7µin (0.50µm) | |
| Current Rating | 5.5A | |
| Voltage - Rated | 660VDC | |
| Operating Temperature | -55°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | JBXFD2G18MCSDSR | |
| Related Links | JBXFD2G, JBXFD2G18MCSDSR Datasheet, Souriau Connection Technology Distributor | |
JBXFD2G18MCSDSR Details Description
