Souriau Connection Technology JBXPC2G05FCSDSMR
- Mfg. Part Number
- JBXPC2G05FCSDSMR
- Manufacturer
- Souriau Connection Technology
- Product Category
- Circular Connectors
- Brief Description
- CONN RCPT 5POS INLINE SKT CRIMP
- Datasheet Download
- JBXPC2G05FCSDSMR.pdf
Availability of JBXPC2G05FCSDSMR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 42.76440
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of JBXPC2G05FCSDSMR, we specialize in Souriau Connection Technology all series electronic components. JBXPC2G05FCSDSMR can be shipped within 24 hours after order. If you have any demands for JBXPC2G05FCSDSMR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- JBXPC2G05FCSDSMR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
JBXPC2G05FCSDSMR
| Internal Part Number | EIS-JBXPC2G05FCSDSMR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | JBX | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 5 | |
| Shell Size - Insert | 2 | |
| Shell Size, MIL | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Crimp | |
| Fastening Type | Push-Pull | |
| Orientation | G | |
| Ingress Protection | IP40 | |
| Shell Material, Finish | Brass, Chrome over Nickel | |
| Contact Finish | Gold | |
| Features | Shielded | |
| Contact Finish Thickness | 19.7µin (0.50µm) | |
| Current Rating | 14A | |
| Voltage - Rated | 900VDC | |
| Operating Temperature | -55°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | JBXPC2G05FCSDSMR | |
| Related Links | JBXPC2G0, JBXPC2G05FCSDSMR Datasheet, Souriau Connection Technology Distributor | |
