Panasonic Electric Works JS1A-5V-F
- Mfg. Part Number
- JS1A-5V-F
- Manufacturer
- Panasonic Electric Works
- Product Category
- Power Relays, Over 2 Amps
- Brief Description
- RELAY GEN PURPOSE SPST 10A 5V
- Datasheet Download
- JS1A-5V-F.pdf
Availability of JS1A-5V-F
Available Quantity
5996 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.87780
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of JS1A-5V-F, we specialize in Panasonic Electric Works all series electronic components. JS1A-5V-F can be shipped within 24 hours after order. If you have any demands for JS1A-5V-F, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- JS1A-5V-F Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
JS1A-5V-F
| Internal Part Number | EIS-JS1A-5V-F | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | General Appl Guidelines Standards Chart How to Read Date Codes | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 100 | |
| Category | Relays | |
| Family | Power Relays, Over 2 Amps | |
| Series | JS | |
| Packaging | Bulk | |
| Relay Type | General Purpose | |
| Coil Type | Non Latching | |
| Coil Current | 72mA | |
| Coil Voltage | 5VDC | |
| Contact Form | SPST-NO (1 Form A) | |
| Contact Rating (Current) | 10A | |
| Switching Voltage | 250VAC, 100VDC - Max | |
| Turn On Voltage (Max) | 3.5 VDC | |
| Turn Off Voltage (Min) | 0.5 VDC | |
| Operate Time | 10ms | |
| Release Time | 10ms | |
| Features | Sealed - Fully | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Contact Material | Silver Tin Oxide (AgSnO) | |
| Coil Power | 360 mW | |
| Coil Resistance | 69.4 Ohms | |
| Operating Temperature | -40°C ~ 70°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | JS1A-5V-F | |
| Related Links | JS1A, JS1A-5V-F Datasheet, Panasonic Electric Works Distributor | |
