C&K Components KSS321GLFS
- Mfg. Part Number
- KSS321GLFS
- Manufacturer
- C&K Components
- Product Category
- Tactile Switches
- Brief Description
- SWITCH TACTILE SPST-NO 0.05A 50V
- Datasheet Download
- KSS321GLFS.pdf
Availability of KSS321GLFS
Available Quantity
9960 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.40260
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of KSS321GLFS, we specialize in C&K Components all series electronic components. KSS321GLFS can be shipped within 24 hours after order. If you have any demands for KSS321GLFS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- KSS321GLFS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
KSS321GLFS
| Internal Part Number | EIS-KSS321GLFS | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Introduction to Electromechanical Switches | |
| RoHS Information | RoHS Cert of Compliance | |
| PCN Design/Specification | KSS Series Material Change 23/Apr/2015 KSS Series 21/Jul/2015 | |
| PCN Other | KSS2 Series 10/Apr/2015 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Tactile Switches | |
| Series | KSS | |
| Packaging | Cut Tape (CT) | |
| Circuit | SPST-NO | |
| Switch Function | Off-Mom | |
| Contact Rating @ Voltage | 0.05A @ 50VDC | |
| Actuator Type | Rectangular Button | |
| Mounting Type | Surface Mount, Right Angle | |
| Actuator Height off PCB, from Pins | - | |
| Actuator Orientation | Side Actuated | |
| Termination Style | Gull Wing | |
| Outline | 7.00mm x 3.50mm | |
| Illumination | Non-Illuminated | |
| Illumination Voltage (Nominal) | - | |
| Illumination Type, Color | - | |
| Operating Force | 200gf | |
| Ingress Protection | IP40 | |
| Features | Tactile Feedback | |
| Actuator Material | - | |
| Switch Travel | 0.30mm | |
| Mechanical Life | 100,000 Cycles | |
| Operating Temperature | -40°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | KSS321GLFS | |
| Related Links | KSS32, KSS321GLFS Datasheet, C&K Components Distributor | |
