Amphenol Commercial Products L77DAH15SOL2
- Mfg. Part Number
- L77DAH15SOL2
- Manufacturer
- Amphenol Commercial Products
- Product Category
- D-Sub Connectors
- Brief Description
- D-Sub Connector Receptacle, Female Sockets 15 Position Through Hole Solder
- Datasheet Download
- L77DAH15SOL2.pdf
Availability of L77DAH15SOL2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.24060
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of L77DAH15SOL2, we specialize in Amphenol Commercial Products all series electronic components. L77DAH15SOL2 can be shipped within 24 hours after order. If you have any demands for L77DAH15SOL2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- L77DAH15SOL2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
L77DAH15SOL2
| Internal Part Number | EIS-L77DAH15SOL2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Communication Solutions Industrial Solutions | |
| Standard Package | 200 | |
| Category | Connectors, Interconnects | |
| Family | D-Sub Connectors | |
| Series | D | |
| Packaging | Tray | |
| Connector Style | D-Sub | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 15 | |
| Number of Rows | 2 | |
| Shell Size, Connector Layout | 2 (DA, A) | |
| Contact Type | Signal | |
| Mounting Type | Through Hole | |
| Flange Feature | Board Side (4-40) | |
| Termination | Solder | |
| Features | - | |
| Shell Material, Finish | Steel, Tin Plated | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 8µin (0.20µm) | |
| Ingress Protection | - | |
| Operating Temperature | -55°C ~ 155°C | |
| Voltage Rating | 300V | |
| Current Rating | 7.5A | |
| Housing Material | Thermoplastic, Glass Filled | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | L77DAH15SOL2 | |
| Related Links | L77DAH, L77DAH15SOL2 Datasheet, Amphenol Commercial Products Distributor | |
