Amphenol Commercial Products L77TWBH5W5S
- Mfg. Part Number
- L77TWBH5W5S
- Manufacturer
- Amphenol Commercial Products
- Product Category
- D-Sub Connectors
- Brief Description
- D-Sub Connector Receptacle, Female Sockets 5 (Power) Position Free Hanging (In-Line) Solder Cup
- Datasheet Download
- L77TWBH5W5S.pdf
Availability of L77TWBH5W5S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.86275
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of L77TWBH5W5S, we specialize in Amphenol Commercial Products all series electronic components. L77TWBH5W5S can be shipped within 24 hours after order. If you have any demands for L77TWBH5W5S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- L77TWBH5W5S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
L77TWBH5W5S
| Internal Part Number | EIS-L77TWBH5W5S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Communication Solutions Industrial Solutions | |
| Standard Package | 200 | |
| Category | Connectors, Interconnects | |
| Family | D-Sub Connectors | |
| Series | TW | |
| Packaging | Bulk | |
| Connector Style | D-Sub, Combo | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 5 (Power) | |
| Number of Rows | 1 | |
| Shell Size, Connector Layout | 3 (DB, B) - 5W5 | |
| Contact Type | Signal and Power | |
| Mounting Type | Free Hanging (In-Line) | |
| Flange Feature | Housing/Shell (Unthreaded) | |
| Termination | Solder Cup | |
| Features | - | |
| Shell Material, Finish | Steel, Tin Plated | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 16µin (0.40µm) | |
| Ingress Protection | - | |
| Operating Temperature | -55°C ~ 155°C | |
| Voltage Rating | 300V | |
| Current Rating | - | |
| Housing Material | Thermoplastic | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | L77TWBH5W5S | |
| Related Links | L77TW, L77TWBH5W5S Datasheet, Amphenol Commercial Products Distributor | |
L77TWBH5W5S Details Description
