Nichicon LLS2D681MELA
- Mfg. Part Number
- LLS2D681MELA
- Manufacturer
- Nichicon
- Product Category
- Aluminum Capacitors
- Brief Description
- CAP ALUM 680UF 20% 200V SNAP
- Datasheet Download
- LLS2D681MELA.pdf
Availability of LLS2D681MELA
Available Quantity
5073 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.84405
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LLS2D681MELA, we specialize in Nichicon all series electronic components. LLS2D681MELA can be shipped within 24 hours after order. If you have any demands for LLS2D681MELA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LLS2D681MELA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LLS2D681MELA
| Internal Part Number | EIS-LLS2D681MELA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Snap-In Cap | |
| Featured Product | LLS Series Aluminum Electrolytic Capacitor | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 250 | |
| Category | Capacitors | |
| Family | Aluminum Capacitors | |
| Series | LS | |
| Packaging | Bulk | |
| Capacitance | 680µF | |
| Tolerance | ±20% | |
| Voltage Rating | 200V | |
| ESR (Equivalent Series Resistance) | - | |
| Lifetime @ Temp. | 3000 Hrs @ 85°C | |
| Operating Temperature | -40°C ~ 85°C | |
| Type | Polar | |
| Applications | General Purpose | |
| Ripple Current | 2.48A | |
| Impedance | - | |
| Lead Spacing | 0.394" (10.00mm) | |
| Size / Dimension | 0.984" Dia (25.00mm) | |
| Height - Seated (Max) | 1.181" (30.00mm) | |
| Surface Mount Land Size | - | |
| Mounting Type | Through Hole | |
| Package / Case | Radial, Can - Snap-In | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LLS2D681MELA | |
| Related Links | LLS2D6, LLS2D681MELA Datasheet, Nichicon Distributor | |
LLS2D681MELA Details Description
