Texas Instruments LM4F232H5QCFIG
- Mfg. Part Number
- LM4F232H5QCFIG
- Manufacturer
- Texas Instruments
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 32BIT 256KB FLASH 100LQFP
- Datasheet Download
- LM4F232H5QCFIG.pdf
Availability of LM4F232H5QCFIG
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LM4F232H5QCFIG, we specialize in Texas Instruments all series electronic components. LM4F232H5QCFIG can be shipped within 24 hours after order. If you have any demands for LM4F232H5QCFIG, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LM4F232H5QCFIG Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LM4F232H5QCFIG
| Internal Part Number | EIS-LM4F232H5QCFIG | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Standard Package | 90 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | Stellaris® ARM® Cortex®-M4F 230 | |
| Packaging | Tray | |
| Core Processor | ARM® Cortex®-M4 | |
| Core Size | 32-Bit | |
| Speed | 80MHz | |
| Connectivity | CAN, I²C, IrDA, LIN, Microwire, QEI, SPI, SSI, UART/USART, USB OTG | |
| Peripherals | Brown-out Detect/Reset, DMA, POR, PWM, WDT | |
| Number of I/O | 69 | |
| Program Memory Size | 256KB (256K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | 2K x 8 | |
| RAM Size | 32K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2.97 V ~ 3.63 V | |
| Data Converters | A/D 22x12b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 100-LQFP | |
| Supplier Device Package | 100-LQFP (14x14) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LM4F232H5QCFIG | |
| Related Links | LM4F232, LM4F232H5QCFIG Datasheet, Texas Instruments Distributor | |
LM4F232H5QCFIG Details Description
