Texas Instruments LMX2330UTM
- Mfg. Part Number
- LMX2330UTM
- Manufacturer
- Texas Instruments
- Product Category
- Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
- Brief Description
- IC FREQ SYNTHESIZER DUAL 20TSSOP
- Datasheet Download
- LMX2330UTM.pdf
Availability of LMX2330UTM
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LMX2330UTM, we specialize in Texas Instruments all series electronic components. LMX2330UTM can be shipped within 24 hours after order. If you have any demands for LMX2330UTM, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LMX2330UTM Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LMX2330UTM
| Internal Part Number | EIS-LMX2330UTM | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 73 | |
| Category | Integrated Circuits (ICs) | |
| Family | Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers | |
| Series | PLLatinum™ | |
| Packaging | Tube | |
| Type | PLL Frequency Synthesizer | |
| PLL | Yes with Bypass | |
| Input | CMOS, TTL | |
| Output | CMOS | |
| Number of Circuits | 1 | |
| Ratio - Input:Output | 3:1 | |
| Differential - Input:Output | Yes/No | |
| Frequency - Max | 2.5GHz, 600MHz | |
| Divider/Multiplier | Yes/No | |
| Voltage - Supply | 2.7 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 20-TSSOP (0.173", 4.40mm Width) | |
| Supplier Device Package | 20-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LMX2330UTM | |
| Related Links | LMX23, LMX2330UTM Datasheet, Texas Instruments Distributor | |
LMX2330UTM Details Description
