Power Integrations LNK460KG
- Mfg. Part Number
- LNK460KG
- Manufacturer
- Power Integrations
- Product Category
- PMIC - LED Drivers
- Brief Description
- IC LED Driver AC DC Offline Switcher Triac Dimming 1A 12-ESOP
- Datasheet Download
- LNK460KG.pdf
Availability of LNK460KG
Available Quantity
5832 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.18000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LNK460KG, we specialize in Power Integrations all series electronic components. LNK460KG can be shipped within 24 hours after order. If you have any demands for LNK460KG, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LNK460KG Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LNK460KG
| Internal Part Number | EIS-LNK460KG | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | MSL Packaging Info | |
| Design Resources | 20 W Non-Isolated Buck LED Driver Using PL LNK460KG Lighting Product Selector | |
| Featured Product | LinkSwitch-PL | |
| Reference Design Library | DER-303: 200mA @ 36V Max, 185 ~ 265 VAC DER-302: 36V @ 200mA, 185 ~ 265VAC in DER-337: 240mA @ 90V Max, 195 ~ 265VAC In DER-336: 40mA @ 145V Max, 195 ~ 265 VAC In DER-322: 230mA @ 81V Max, 195 ~ 265 VAC in DER-328: 280mA @ 36V, 90 ~ 132 VAC in DER-323: 200mA @ 90V Max, 90 ~ 135VAC in DER-305: 200mA @ 50V Max, 185 ~ 265VAC in DER-306: 278mA @ 36V Max, 90 ~ 135VAC in DER-345: 235mA @ 90V Max, 85 ~ 135VAC in | |
| PCN Packaging | Multiple Devices 15/Mar/2011 | |
| Standard Package | 48 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - LED Drivers | |
| Series | LinkSwitch®-PL | |
| Packaging | Tube | |
| Type | AC DC Offline Switcher | |
| Topology | - | |
| Internal Switch(s) | Yes | |
| Number of Outputs | 1 | |
| Voltage - Supply (Min) | - | |
| Voltage - Supply (Max) | 50V | |
| Voltage - Output | - | |
| Current - Output / Channel | 1A | |
| Frequency | 122kHz | |
| Dimming | Triac | |
| Applications | - | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 12-BESOP (0.350", 8.89mm Width) 11 Leads, Exposed Pad | |
| Supplier Device Package | 12-ESOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LNK460KG | |
| Related Links | LNK4, LNK460KG Datasheet, Power Integrations Distributor | |
