Texas Instruments LOG102AIDG4
- Mfg. Part Number
- LOG102AIDG4
- Manufacturer
- Texas Instruments
- Product Category
- Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
- Brief Description
- IC OPAMP LOGARITHMIC 1.4MHZ 14SO
- Datasheet Download
- LOG102AIDG4.pdf
Availability of LOG102AIDG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 10.19625
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LOG102AIDG4, we specialize in Texas Instruments all series electronic components. LOG102AIDG4 can be shipped within 24 hours after order. If you have any demands for LOG102AIDG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LOG102AIDG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LOG102AIDG4
| Internal Part Number | EIS-LOG102AIDG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps | |
| Series | - | |
| Packaging | Tube | |
| Amplifier Type | Logarithmic and Log Ratio | |
| Number of Circuits | 1 | |
| Output Type | - | |
| Slew Rate | 0.5 V/µs | |
| Gain Bandwidth Product | 1.4MHz | |
| -3db Bandwidth | 45kHz | |
| Current - Input Bias | 5pA | |
| Voltage - Input Offset | 300µV | |
| Current - Supply | 1.25mA | |
| Current - Output / Channel | 18mA | |
| Voltage - Supply, Single/Dual (±) | ±4.5 V ~ 18 V | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 14-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LOG102AIDG4 | |
| Related Links | LOG10, LOG102AIDG4 Datasheet, Texas Instruments Distributor | |
LOG102AIDG4 Details Description
