TT Electronics/IRC LRF3WLF-01-R010F
- Mfg. Part Number
- LRF3WLF-01-R010F
- Manufacturer
- TT Electronics/IRC
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 0.01 OHM 1% 3W 1225
- Datasheet Download
- LRF3WLF-01-R010F.pdf
Availability of LRF3WLF-01-R010F
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.31220
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LRF3WLF-01-R010F, we specialize in TT Electronics/IRC all series electronic components. LRF3WLF-01-R010F can be shipped within 24 hours after order. If you have any demands for LRF3WLF-01-R010F, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LRF3WLF-01-R010F Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LRF3WLF-01-R010F
| Internal Part Number | EIS-LRF3WLF-01-R010F | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Current Sense Resistor Products | |
| RoHS Information | RoHS Cert of Compliance | |
| Standard Package | 1,800 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | LRF3W | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 0.01 | |
| Tolerance | ±1% | |
| Power (Watts) | 3W | |
| Composition | Thick Film | |
| Features | Current Sense, Moisture Resistant | |
| Temperature Coefficient | ±100ppm/°C | |
| Operating Temperature | -55°C ~ 150°C | |
| Package / Case | Wide 2512 (6432 Metric), 1225 | |
| Supplier Device Package | 1225 | |
| Size / Dimension | 0.125" L x 0.250" W (3.18mm x 6.35mm) | |
| Height | 0.035" (0.89mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LRF3WLF-01-R010F | |
| Related Links | LRF3WLF-, LRF3WLF-01-R010F Datasheet, TT Electronics/IRC Distributor | |
LRF3WLF-01-R010F Details Description
