Linear LT1764AMPQ#PBF
- Mfg. Part Number
- LT1764AMPQ#PBF
- Manufacturer
- Linear
- Product Category
- PMIC - Voltage Regulators - Linear
- Brief Description
- IC REG LDO ADJ 3A 5DDPAK
- Datasheet Download
- LT1764AMPQ#PBF.pdf
Availability of LT1764AMPQ#PBF
Available Quantity
5095 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 10.53000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LT1764AMPQ#PBF, we specialize in Linear all series electronic components. LT1764AMPQ#PBF can be shipped within 24 hours after order. If you have any demands for LT1764AMPQ#PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LT1764AMPQ#PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LT1764AMPQ#PBF
| Internal Part Number | EIS-LT1764AMPQ#PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Low Dropout Linear Regulator Frequently Asked Questions | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - Linear | |
| Series | - | |
| Packaging | Tube | |
| Regulator Topology | Positive Adjustable | |
| Voltage - Output | 1.21 V ~ 20 V | |
| Current - Output | 3A | |
| Voltage - Dropout (Typical) | 0.34V @ 3A | |
| Number of Regulators | 1 | |
| Voltage - Input | 2.7 V ~ 20 V | |
| Current - Limit (Min) | 3.1A | |
| Operating Temperature | -55°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-263-6, D²Pak (5 Leads + Tab), TO-263BA | |
| Supplier Device Package | 5-DDPAK | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LT1764AMPQ#PBF | |
| Related Links | LT1764A, LT1764AMPQ#PBF Datasheet, Linear Distributor | |
LT1764AMPQ#PBF Details Description
