Linear LTC1272-3ACSW
- Mfg. Part Number
- LTC1272-3ACSW
- Manufacturer
- Linear
- Product Category
- Data Acquisition - Analog to Digital Converters (ADC)
- Brief Description
- IC A/D CONV 12BIT SAMPLNG 24SOIC
- Datasheet Download
- LTC1272-3ACSW.pdf
Availability of LTC1272-3ACSW
Available Quantity
5032 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 28.14000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTC1272-3ACSW, we specialize in Linear all series electronic components. LTC1272-3ACSW can be shipped within 24 hours after order. If you have any demands for LTC1272-3ACSW, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTC1272-3ACSW Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTC1272-3ACSW
| Internal Part Number | EIS-LTC1272-3ACSW | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | General Purpose SAR ADCs | |
| Standard Package | 32 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Analog to Digital Converters (ADC) | |
| Series | - | |
| Packaging | Tube | |
| Number of Bits | 12 | |
| Sampling Rate (Per Second) | 250k | |
| Number of Inputs | 1 | |
| Input Type | Single Ended | |
| Data Interface | Parallel | |
| Configuration | S/H-ADC | |
| Ratio - S/H:ADC | 1:1 | |
| Number of A/D Converters | 1 | |
| Architecture | SAR | |
| Reference Type | Internal | |
| Voltage - Supply, Analog | 5V | |
| Voltage - Supply, Digital | 5V | |
| Features | - | |
| Operating Temperature | 0°C ~ 70°C | |
| Package / Case | 24-SOIC (0.295", 7.50mm Width) | |
| Supplier Device Package | 24-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTC1272-3ACSW | |
| Related Links | LTC127, LTC1272-3ACSW Datasheet, Linear Distributor | |
LTC1272-3ACSW Details Description
