Linear LTC2382CMS-16#TRPBF
- Mfg. Part Number
- LTC2382CMS-16#TRPBF
- Manufacturer
- Linear
- Product Category
- Data Acquisition - Analog to Digital Converters (ADC)
- Brief Description
- IC ADC 16BIT 1CH 500KSPS 16-MSOP
- Datasheet Download
- LTC2382CMS-16#TRPBF.pdf
Availability of LTC2382CMS-16#TRPBF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 10.42002
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTC2382CMS-16#TRPBF, we specialize in Linear all series electronic components. LTC2382CMS-16#TRPBF can be shipped within 24 hours after order. If you have any demands for LTC2382CMS-16#TRPBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTC2382CMS-16#TRPBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTC2382CMS-16#TRPBF
| Internal Part Number | EIS-LTC2382CMS-16#TRPBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | General Purpose SAR ADCs | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Analog to Digital Converters (ADC) | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Number of Bits | 16 | |
| Sampling Rate (Per Second) | 500k | |
| Number of Inputs | 1 | |
| Input Type | Differential | |
| Data Interface | SPI | |
| Configuration | S/H-ADC | |
| Ratio - S/H:ADC | 1:1 | |
| Number of A/D Converters | 1 | |
| Architecture | SAR | |
| Reference Type | External | |
| Voltage - Supply, Analog | 2.375 V ~ 2.625 V | |
| Voltage - Supply, Digital | 2.375 V ~ 2.625 V | |
| Features | - | |
| Operating Temperature | 0°C ~ 70°C | |
| Package / Case | 16-TFSOP (0.118", 3.00mm Width) | |
| Supplier Device Package | 16-MSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTC2382CMS-16#TRPBF | |
| Related Links | LTC2382CM, LTC2382CMS-16#TRPBF Datasheet, Linear Distributor | |
LTC2382CMS-16#TRPBF Details Description
