NKK Switches M2023LL1A01
- Mfg. Part Number
- M2023LL1A01
- Manufacturer
- NKK Switches
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE DPDT 6A 125V
- Datasheet Download
- M2023LL1A01.pdf
Availability of M2023LL1A01
Available Quantity
5030 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.82400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of M2023LL1A01, we specialize in NKK Switches all series electronic components. M2023LL1A01 can be shipped within 24 hours after order. If you have any demands for M2023LL1A01, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- M2023LL1A01 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
M2023LL1A01
| Internal Part Number | EIS-M2023LL1A01 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Switch Basics 3D CAD Models | |
| RoHS Information | Series, Cert of Compliance | |
| Featured Product | M Series Miniature PCB Toggle Switches | |
| 3D Model | M2023LL1A01 | |
| PCN Design/Specification | Multiple Devices O-ring 30/Jun/2011 M Series Toggles, rockers, Pushbuttons CSA Mark Size 23/Jul/2015 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | M | |
| Packaging | Bulk | |
| Circuit | DPDT | |
| Switch Function | On-Off-On | |
| Current Rating | 6A (AC), 3A (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Locking Lever | |
| Actuator Length | 16.50mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount | |
| Termination Style | Solder Lug | |
| Panel Cutout Dimensions | Circular - 6.50mm Dia | |
| Bushing Thread | 1/4-40 | |
| Ingress Protection | - | |
| Features | Epoxy Sealed Terminals | |
| Actuator Material | Brass, Chrome Plated | |
| Electrical Life | 25,000 Cycles | |
| Operating Temperature | -30°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | M2023LL1A01 | |
| Related Links | M2023, M2023LL1A01 Datasheet, NKK Switches Distributor | |
