NKK Switches M2047L1L1W01
- Mfg. Part Number
- M2047L1L1W01
- Manufacturer
- NKK Switches
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE DP3T 6A 125V
- Datasheet Download
- M2047L1L1W01.pdf
Availability of M2047L1L1W01
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 15.61000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of M2047L1L1W01, we specialize in NKK Switches all series electronic components. M2047L1L1W01 can be shipped within 24 hours after order. If you have any demands for M2047L1L1W01, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- M2047L1L1W01 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
M2047L1L1W01
| Internal Part Number | EIS-M2047L1L1W01 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | M Series Toggles, rockers, Pushbuttons CSA Mark Size 23/Jul/2015 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | M | |
| Packaging | Bulk | |
| Circuit | DP3T | |
| Switch Function | On-On-Mom | |
| Current Rating | 6A (AC), 3A (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Locking Lever | |
| Actuator Length | - | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount | |
| Termination Style | Solder Lug | |
| Panel Cutout Dimensions | Circular - 6.50mm Dia | |
| Bushing Thread | 1/4-40 | |
| Ingress Protection | - | |
| Features | Jumper needed to achieve triple throw | |
| Actuator Material | Brass, Chrome Plated | |
| Electrical Life | 25,000 Cycles | |
| Operating Temperature | -30°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | M2047L1L1W01 | |
| Related Links | M2047L, M2047L1L1W01 Datasheet, NKK Switches Distributor | |
